GENIUS TOOLS for Windchill
Windchill customising without programming
Transfer of release information from the approval process
Automatic alignment of the Windchill release and change history to Creo without user-interaction and transferring drawing title block information to Creo.
Process-controlled BOM export
Automatic BOM and/or metadata export to XML or CSV and BOM export to different formats for downstream processing in enterprise systems such as ERP.
Status related export of neutral formats to hard disk
Quick access to documents for distribution to other departments, machines, ERP systems and customers without manual intraction.
show more
Enhanced visualisation service
Automatically generate various neutral formats for a CAD document. Purge obsolete visualisations. Download complete drawing folders.
Operational reliability – OEM supported
No rework required when updating, ensured compatibility with new Windchill releases.
Fully integrated into Windchill
Individual Windchill configuration without programming, directly integrated into Windchill settings manager.Customisation as a standard
The implementation of company-specific processes in an organisation’s PDM system mostly requires custom programming. GENIUS TOOLS for Windchill from INNEO solves this problem bringing together the many years of experience of our Windchill experts in a set of Windchill extension modules allowing you to define your individual PDM processes directly in the Windchill browser interface without specific programming and the associated issues of updating to support a new release.
Features Overview
- Automatic alignment of the Windchill release and change history to Creo
- Populate drawing title block information in Creo
- Process-driven BOM export
- Automatically generate various neutral formats for a CAD document
- Purge obsolete visualisations
- Download complete drawing folders
- Status related export of neutral formats to hard disk
- Automatic BOM and/or metadata export to XML or CSV
- Individual Windchill configuration without programming
- Integrated into Windchill settings manager.
GENIUS TOOLS for Windchill Modules
| Task | Enhanced Publishing |
Viewable Export | BOM Export | Release Information Delegate |
|---|---|---|---|---|
| Generate various neutral / visualisation formats simultaneously using time-based filters / status (P (PDF, DXF, DWG, HPGL, CGM, STEP, IGES) | ||||
| Publish “Latest”, “As stored” or “As released“ state depending on lifecycle | ||||
| Purge previous versions of an assembly, part or drawing | ||||
| Status related export of neutral / visualisation formats to hard disk / file server (PDF, DXF, DWG, HPGL, CGM, STEP, IGES) | ||||
| Execute custom post processes for subsequent operations e.g. transfer to 3rdparty systems | ||||
| Naming of output formats driven by attributes | ||||
| BOM output to XML or CSV | ||||
| Export article master data to meta files | ||||
| Transfer of release / reviewer information and change history to drawing title block |
Contact us to find out more about GENIUS TOOLS for Windchill
