GENIUS TOOLS Model Processor
Make sure your CAD files comply with latest CAD company standards! Uniform model quality of inventory and new CAD data is the key to increased design productivity.
Edit model properties
Update inventory data to comply with latest company standards and use custom features for Creo Parametric
Analyse models
Identify shortcomings with detailed reports
Edit any amount of data
Process thousands of files in a single step.
show more
Common uses cases
- Adapting 3rd party or supplier data to company standards
- Preparing model data for PDM/PLM implementation
- Adapting catalogue parts to company standards
- Consolidating CAD data (e.g. company acquisition)
- Trigger: automated processing of action lists when loading and saving Creo models
For CAD Users
- Working off Creo data interactively during the CAD session (e.g. adapting external data to company standards, rework data from a PDM system…)
- Adapting catalogue parts to company standards
- Custom Creo Functionality (QR code, colour assignment, …)
For CAD/PDM executives, administrators
Full data pool processing and examination:
- Examination, reworking and clearing-up
- Consolidating Creo data pools
- Modification of CAD standards
- Modification of the parameter concept
- Modification of the layer concept
Edit any amount of data
GENIUS TOOLS Model Processor supports you consistently in standardising your inventory Creo Parametric data. Be it clearing up existing CAD data sets, consolidating CAD data (company acquisition) or preparation for CAD data management: With Model Processor you can automate timeconsuming and error-prone manual tasks.
GENIUS TOOLS Model Processor capabilities
More than 180 actions enable you to edit the different properties of your Creo parts, assemblies and drawings:
- combined states
- simplified representations
- change drawing title box, “clean-up” drawings
- feature colours depending on dimensions and tolerances
- creating a QR codes (symbol in drawings, pattern in 3D)
- using mapkeys with OS variables and model parameters
- layers, layer states
- parameters, relations, cross sections
- material, units, accuracy, tolerances
- family tables (verify, resolve…)
- views, export, image creation
show more
Possible editing modes
- apply to current model
- revise all models in memory or workspace
- edit a database from a PDM system (read a generated file name list) or from hard drive
- generate new models by applying the appropriate actions
- single step mode
- material browser
- convert *.mat to *.mtl
- material overview (table)
- add material parameter
- simple editing via tables
Product Versions Matrix
| Task | GENIUS TOOLS Model Processor Guest mode |
GENIUS TOOLS Model Processor User |
GENIUS TOOLS Model Processor Report |
GENIUS TOOLS Model Processor Rework |
GENIUS TOOLS Model Processor Worker Extension |
|---|---|---|---|---|---|
| Creation and modification of action lists | |||||
| Execution of pre-defined action lists | |||||
| Edit current Creo model | |||||
| Edit models in session/ workspace |
|||||
| Batch processing for creating reports |
|||||
| Batch processing with editing Creo models |
|||||
| Licensing | free registration, no license required |
floating license, bound to Creo session | concurrent (floating) | concurrent (floating) | designated Computer |
